Yamaha 40HP Jet Drive offers practical and efficient performance for compact boats operating in confined or debris-prone waters. Its jet-driven system enables controlled navigation while maintaining reliability and ease of use.
Stock is continuously maintained to meet global demand, allowing immediate dispatch to customers across various sectors. From single purchases to larger requirements, supply is structured to deliver quickly and consistently without interruption.
Product Media
Specifications
40 HP
Our 747-cc F40 Jet Drive outboard produces 30 hp at the pump. Its compact, lightweight SOHC three-cylinder, in-line design features a long-track induction system and a single throttle valve. This creates compact, light-weight power and improves throttle response for shallow streams.
- 219 pounds (including jet pump assembly)
- Fits 20-inch transom boats
- Solid 16-amp alternator
- Nitro Assist Tilt
40 HP
| Weight † | 99 kg (219lbs) – 103 kg (227 lbs) |
|---|---|
| Full Throttle RPM Range | 5000 ~ 6000 rpm |
| Fuel Induction System | EFI |
| Recommended Engine Oil | Yamalube® 4M (See owner’s manual) |
| Engine Type | 3 cyl |
| Displacement | 747cc |
| Bore x Stroke | 65 x 75 mm (2.56 x 2.95 in) |
| Prop Shaft Horsepower | 30hp @ 5500rpm |
| Alternator Output at W.O.T. | 16 Amp |
| Compression Ratio | 9.4:1 |
| Recommended Fuel | Octane 87 |
| Recommended Fuel Filtration | Yamaha 10-Micron Fuel/Water Separating Filter (external) |
| C.A.R.B. Rating | 2-Star |
| Exhaust | Through Jet Nozzle |
| Intake | 6 |
| Ignition | CDI Microcomputer |
| Spark Plug | DPR6EB-9 |
| Starting System | Electric |
| Lubrication | Wet Sump |
| Engine Oil Capacity | 1.7L/1.5L |
| Recommended Cooling | Thermostatic Control |
| Ethanol Blend Limit | 10% Maximum |
| Gear Ratio | Direct Drive |
| Gear Shift | Forward, Neutral, Reverse |
| Shaft Length | Fits 20″ Transom |
| Degree of Tilt | 65° |
| Degree of Trim | –4° through +16° |
| Mounting Centers | N/A |
| Steering | |
| Steering Angle (maximum) | 40° from center, either direction |
| Warranty | Limited 3 Year Limited Pleasure Boat – 1 Year Limited Commercial |
